Description
A firm grip on powerful sound
A special three-way bass reflex construction incorporates six individual units – two each for treble, mid-range and bass. Each driver is powered by a unique built-in ICEpower amplifier, delivering a combined effect of 750 watt. In addition, BeoLab 7-1 and 7-2 are equipped with thermal protection circuits and Adaptive Bass Linearisation (ABL), which ensures maximum performance without distortion, even at very high volume. Bang & Olufsen has a quarter of a century of experience making loudspeaker cabinets from extruded aluminium. This technique allows for very rigid and compact enclosures with powerful sound performance.
Specifications:
Cabinet finish
Aluminium cabinet coated with hardwearing black soft-touch lacquer. Speaker grille in natural coloured anodised aluminium
Power consumption IEC65: 36 watt
Typical: 20 W
Stand-by: 0.2 W
Power amplifiers (per channel) 3 x 125 watts, Class D, ICEpowerÒ
Long-term maximum output power
per amplifier Bass: 120 watts/8 ohm
Midrange: 120 watts/8 ohm
Treble: 120 watts/8ohm
Effective Frequency range 37 – 20.000 Hz
Crossover frequencies 250 Hz and 4.000 Hz
Cabinet principle Bass: Bass reflex
Midrange/Treble: Closed box
Net volume, bass 4.2 litres (per side)
Net volume, midrange 0.8 litres (per side)
Magnetically shielded No
Woofer 101,6 mm
Midrange 76,2 mm
Tweeter 19 mm
Input sensitivity (Power Link) 88dB @ 125 mV SPL
Indicator (for service use only) 1 tri-colour LED. Green for On, Red for Off, Orange for Protection mode
Operation Free or Wall position
Protection Thermal protection
Connections:
Power Link 1 (Semi-Balanced PL cable type MK III, or fully mounted PL cable required)
Mains 1 input, 1 output (not US version)
